9
TECHNICAL SPECIFICATIONS - 2U MODELS
Model Name
PDU81003
PDU71003
PDU41003
PDU31003
PDU81007
PDU71007
PDU41007
PDU31007
PDU81008
PDU71008
PDU41008
PDU31008
PDU81009
PDU71009
PDU41009
PDU31009
Input
Nominal Voltage 100 - 120 V 200 - 240 V
Frequency 50 / 60Hz
Maximum Input Current 24A UL (Derated)
Plug Type NEMA L5-30P NEMA L6-30P
Power Cord Type SR (10 AWG)
Power Cord Length 12 ft / 3.65 m
Output
Nominal Voltage 100 - 120 V 200 - 240 V
Maximum Output Current 24A UL (Derated) / 20A Per Bank
Band Number 2
Outlet Type NEMA 5-20R IEC C13 12 IEC C13 / 4 IEC C19 IEC C19
Circuit Breaker Yes
Management and Communications
Multifunction
LCD Readout
Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (Height x
Width x Depth)
3.5 x 17.05 x 4.41 in. / 88 x 433 x 112 mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11,480 ft / 3,500 m
Temperature 32°F to 140° F / 0° C to 60° C
Safety Approvals
Certifications UL 60950-1 / FCC Class A
All specifications are subject to change without notice.
