21
Step 2. Cord Retention Tray Installation (optional)
Adjust the length of the Cord Retention Tray till the screw hole on the Tray and PDU are aligned.
Attach the Cord Retention Tray to the PDU with the supplied Cord Retention Tray Mounting Screws.
Tighten the Cord Retention Tray with the screw on it.
INSTALLATION GUIDE
Vertical Installation - OU Models
Use the provided Cable Ties to fasten each cord to the Cord Retention Tray.
Note: If the PDUs are intended to install in a high temperature environment, please use the Power Cords that could sustain
high temperature operation.
To Next Page
