29
6. Select Upgrade Firmware.
7. Click B rows e to locate and select the firmware and data
file to be updated (Figure 4).
8. Click OK in the Upgrade Firmware confirmation window
(Figure 5).
9. The upgrade progress bar will show in Last Action
column (Shown in Figure 6).
4. Check the checkbox to select devices listed in the
Operation View (Figure 2).
5. Make sure Account and Pa sswo rd are valid on selected
devices (Figure 3).
OPERATION
Firmware Upgrade
Figure 4
Figure 5
Figure 6
Figure 2
Figure 3
10. The result of firmware upgrade will show in Result
column (Shown in Figure 7).
Note: If you don’t want to wait for the firmware upgrade,
you can stop action by choosing Abort in the Action menu.
However, it’s not recommended because Abort action may
cause the device to malfunction.
Figure 7
