24" (62 cm)1
23' (58 cm)1
65" (165 cm)248" (122 cm)2
Choosing and Preparing a Site
Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
• Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches (0.6 meters).
• Adjacent units may share the free area.
Free area
525R525C
23.6”, 0.6m1
23.6”, 0.6m1
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
Page 12 of 80
Cybex 525C/525R Cycle Part Number LT-24303-4 E
