CYBEX 525C - User Controls

Displays Time, BPM, or Weight.Left enunciator1
Displays value of Time, BPM, or Weight.Left data readout2
Displays workout profiles and setup options.Bar graph3
Displays Calories, RPM, or Cal/Hour.Right enunciator4
Displays value of Calories, RPM, or Cal/Hour.Right data readout5
Figure 6: E3 View Monitor
User Controls
Setup key11Resistance keys6Resistance keys1
Enter key12Volume keys7Gear/level display2
Up/Down keys13Display option key8Quick Start key3
Headphone jack9Workouts key4
STOP key10Resistance display5
Gear, Level, and Resistance is shown in the LED displays. The Up/Down LED
indicates when Up/Down keys are active to change settings.
Displays
