Assembly
Page 5-8
Cybex Free Weight Owner’s Manual
ITEM QTY PART NO. DESCRIPTION
4 2 HS387700 Washer SAE .50
5 2 JC780417 BHSCS .50-13 x 1.00
6 6 PP080202 Plastic Insert 1.19 Dia.
14 2 5330C042 Spacer Plate
15 12 HN784000 Hex Nut .50-13
16 10 JC782817 SHCS .50-13 x 1.00
17 2 JC782824 SHCS .50-13 x 1.75
18 12 JS388300 Lockwasher .50
28 1 55420 Assembly Instructions
(not shown)
Figure 4
