Parts List
ITEM PART NO. DESCRIPTION
NO.
1 AF-16240 Frame, Weldment
2 HS-16929 Screw, 3-8-16 x 5-8Lg H x HD whiz-lock GR5
3 HS-16950 Screw, 5-16-18 x 7-8Lg H x Soc BTNHD w/patch, B-Zn
4 HS-16939 Screw, SEM 10-32 x .75 Pnhd Ext blk Zn
5 PL-16256 Cover, Motor
6 PL-16465 Cover, Upright Outer, Right
7 PL-16464 Cover, Upright Outer, Left
8 HW-13799 Washer, Flat
9 AX-16721 Deck Stiffener Assy
9 AF-16161 Stiffener, Deck
10 HX-16706 Tape Strip, 1.88 x 41.0 x .010thk
11 HX-16707 Tape Strip, 1.32 x 4.30 x .010thk
12 HS-15682 Screw, 5/16-18 x .50 FLHD Phil undercut ZN
13 AX-16873 Side Extrusion Assy, Pro, Left
14 AX-16874 Side Extrusion Assy, Pro, Right
15 AF-16325 Upright Weldment (Choose a Standard or Custom Color)
16 AX-16722 Top Platform Assy, (Choose a Standard or Custom Color)
17 DE-16705 Decal, Safety-walk
18 HS-16875 Screw, SEM ext 1-4-20 x 1-2 PNHD Phil
19 EH-10291 Anchor, Cable Tie
20 EH-00986 Cable Tie, (without anchor)
21 PL-16738 Plug, Power Cord Grommet
21 AW-16639 Power Cord, 220V 60Hz (NOT SHOWN)
21 AW-16638 Power Cord, 230V 50Hz (NOT SHOWN)
21 AW-16640 Power Cord, 115V 60Hz (NOT SHOWN)
22 PL-16737 Grommet, .45 ID, Power Cord
23 DE-16992 Decal, ETL UL-1647 Only
24 Not Available Decal, Serial Number, Cybex
25 RC-16496 End Cap, Left, (Choose a Standard or Custom Color)
26 RC-16497 End Cap, Right, (Choose a Standard or Custom Color)
27 HX-15678 Bushing Deck 5/16-18 40 lb max shear 185 max comp
28 EH-16809 Grommet, 1.12 x .091-.125 nylon
29 HX-14416 Clip, Cable Retainer
30 DE-16928 Label, Disconnect Power, Multi-languages
31 HW-00590 Bushing Nylon 1-2” Nf810-5-0
32 HX-13771 Ring, Retain 5-8” .579 Fr.Id
33 HX-16510 Foot, Rubber, Rear
34 FS-16511 Plate, Rear Rubber Foot Mount
35 HS-16509 Screw, #10 x .5LG,T-S PLT, PNHD,TYB-B
36 HS-15480 Bolt, Tap 1/2-13unc x 6 H x HD GR5
37 HB-16367 Bushing, .50ID x .62OD x .31LG, flanged
38 HW-10028 Washer, B 1-2 Narrow Zinc
39 HX-11049 Spring 1" O.D.360 Max Ld.
40 AX-16723 Rear Roller Hardware Assembly
41 AF-16382 Elevation, Weldment
42 HS-60022 Bolt, Hhcs 0.375 x 2.25 blk zn G5
43 CW-16712 Wheel, Rubber, 3" Dia
44 HN-60064 Nut, Jam 3-8”-16 blk zn
46 HS-60021 Bolt, Hhcs 0.375 x 2 blk zn G5
47 HS-60023 Bolt, Hhcs 0.375 x 2.5 blk zn G5
48 MR-16412 Motor, Elevation 115 VAC
48 MR-16541 Motor, Elevation 230 VAC
49 HX-16965 Tube Nut, Motor, Elevation
50 FT-16825 Sleeve, Elevation Mounting, Top
51 FT-16826 Sleeve, Elevation Mounting, Bottom
52 EC-15783 Filter, Line 20 Amp Spade
52 EC-16948 Filter, Power Line 20 Amp 20EQ1
53 HS-15732 Screw, SEM 8-32 unc x .62 PNHD phil pl
54 HW-10856 Washer, (for ground)
Cybex Pro Treadmill Owner’s & Service Manual
Page 7-36
