Note: Leave a spacing of 5-12mm between washer and upright.
2. Slide bridge down uprights.
QtyDescriptionItem
1Bridge1
2Upright2
3. Install bolts, washers, and lock nuts securing the bridge to uprights using a 13mm socket and wrench.
QtyDescriptionItem
1Bridge1
2Upright2
2Lock Nut, M83
4Washer, M84
2Bolt, M8 x 20mm Hex Head5
