Program The AD4 Card Number Given Any Output Address - Macro 96
Macro 96 is only used when the AD4 is connected to the programming track. It accepts an output
address, 1-2045, and programs CV513 and 521 for the appropriate card number. The display will
then show you the three additional output addresses now available on the card. There is no need
to worry about manually loading the LSB and MSB CVs. This macro does that automatically.
For this example, the AD4 needs to be programmed so that one of the output addresses is 600.
mSVC PRGM, [m3 ] if the first message is not as shown
m MACRO
m 9, m6, m ENT
m6, m 0, m0 This is the output address, not the card number.
m ENT,
m ESC to return to the home page
The last message, before pushing ESC, shows that the accessory decoder has been programmed
so that the output address associated with the A output is 597, B output is 598, C output is 599 and
the D output address is 600.
Accessory Decoder [AD4] Programming
Program Track
Program What?
Program Track
Macro# __?
Program Track
Macro# 96__?
Progr Accessory
Output/Rt# ____?
Progr Accessory
Output/Rt# 600_?
Progr Accessory
Addr=0597---0600
Use Macro 97 to check the values loaded into the
AD4. See page 98 for step-by-step details on how to
use Macro 97.
