© 2021 Cypress Solutions Manual: CTM-ONE (Revision 1.0)
For optimum performance antennas should be mounted in a vertical orientation as high up as possible and with
clear line of sight in all directions. For regulatory purposes it must be mounted in such a position as to maintain
a separation distance from any person of at least 20cm (8”).
The decision to use external antennas should be made based on performance evaluation of how the product
performs when placed in the desired location within the vehicle or fixed site.
5.5.1 Cellular
The cellular connection supports MIMO (multi-in multi-out) for LTE Category 1 and 4 models. For best
performance ensure both primary and secondary cellular antenna connections are made to an antenna that
supports diversity or to two separate antennas.
CTM-ONE B2,4,12,13,17
CTM-ONE M GLOBAL B1,2,3,4,5,8,12,13,18,19,20,25,26,28
CTM-ONE PLUS B2,4,12,13,14,66,71
CTM-ONE/PLUS II,IV,V
CTM-ONE M 850/900/1800/1900 Mhz
5.5.2 GNSS
The GNSS antenna should be an active type of antenna with a gain of at least 26dB and compatible with a 3.3
volt DC supply provided directly by the CTM-ONE via the coax cable. The antenna installation should typically be
on an upper horizontal surface of a vehicle or building with a clear 360-degree view of the sky.
Connect a suitable GPS antenna to the port labeled “GPS”. For best performance select a GPS antenna that
supports GPS/Glonass/Beidou/Compass/Galileo/QZSS (GNSS) constellations.
