The CTM-ONE supports supply voltages ranging between 7 VDC and 32 VDC.
The Chameleon CTM-ONE gateway has three power modes:
Device is in low power mode; higher
current allows for more features
such as instant boot.
Linux is not running.
The device will spend most of its time in this
mode, triggers such as timer, or input state
change will bring the device out of this
mode into Operating System mode.
Linux is operating, device can
communicate with peripherals,
Serial, Ethernet, CAN, GPIO, GNSS
Processing of data, MODBUS
operations.
The device will go back into standby mode
when the ignition/standby signal is
deactivated or upon expiry of the power ON
timer if configured.
In this mode the device is
transmitting/receiving data
Transmit time will typically be very short,
few seconds or less due to typical low data
payloads.
