8D-Link DAP-1513 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4)
Connect10/100Ethernetdevicessuchascomputers,cameras,andNAS(Network-Attached
Storage).
2 Power Receptor Receptor for the supplied power adapter.
3 Reset Button
Hold the reset button for at least 6 seconds to reset the device back to the factory default
settings. All the LEDs will turn on for 2 second and then begin the reboot process.
1
2
3
