DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Overview
The RESET and WPS buttons are located on the upper panel of the extender.
Button Description
RESET
A button to restore the factory default settings.
To restore the factory defaults, push the button (with the device turned
on), hold it for 10 seconds, and then release the button.
WPS
A button to set up a wireless connection (the WPS function).
To use the WPS function: with the device turned on, push the button,
hold it for 2 seconds, and release. The POWER/WPS LED should
start blinking.
The device is also equipped with two external non-detachable Wi-Fi antennas.
Bottom Panel
Figure 2. Bottom panel view.
Port Description
LAN An Ethernet port to connect to a computer or a wired router.
Page 11 of 91
