Overview
Wireless Module Parameters
· 802.11ac (typical at PER = 10% (1000-byte PDUs))
HT20
-82dBm at MCS0
-79dBm at MCS1
-77dBm at MCS2
-74dBm at MCS3
-70dBm at MCS4
-66dBm at MCS5
-65dBm at MCS6
-64dBm at MCS7
-59dBm at MCS8
-57dBm at MCS9
HT40
-79dBm at MCS0
-76dBm at MCS1
-74dBm at MCS2
-71dBm at MCS3
-67dBm at MCS4
-63dBm at MCS5
-62dBm at MCS6
-61dBm at MCS7
-56dBm at MCS8
-54dBm at MCS9
HT80
-79dBm at MCS0
-73dBm at MCS1
-71dBm at MCS2
-68dBm at MCS3
-64dBm at MCS4
-60dBm at MCS5
-59dBm at MCS6
-58dBm at MCS7
-53dBm at MCS8
-51dBm at MCS9
Modulation schemes · 802.11a: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11g: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM with OFDM
Physical Parameters
Dimensions (L x W x H)
· 51 x 49 x 98 mm (2 x 1.91 x 3.85 in)
Weight
· 120 g (0.26 lb)
Operating Environment
Power
· Input: 110 to 240 V AC, 50/60 Hz
Temperature · Operating: from 0 to 40 °C
· Storage: from -20 to 70 °C
Humidity · Operating: from 10% to 90% (non-condensing)
· Storage: from 5% to 90% (non-condensing)
Page 9 of 91
