DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Overview
Wireless Module Parameters
Standards · IEEE 802.11a/n/ac
· IEEE 802.11b/g/n
Frequency range · 2400 ~ 2483.5MHz
· 5150 ~ 5350MHz
· 5650 ~ 5725MHz
Wireless connection security · WEP
· WPA/WPA2 (Personal/Enterprise)
· МАС filter
· WPS (PBC/PIN)
Advanced functions · Support of client mode
· WMM (Wi-Fi QoS)
· Information on connected Wi-Fi clients
· Advanced settings
· Smart adjustment of Wi-Fi clients
· Support of MBSSID
· Periodic scan of channels, automatic switch to least loaded channel
· Autonegotiation of channel bandwidth in accordance with environment
conditions (20/40 Coexistence)
Wireless connection rate · IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54Mbps
· IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps
· IEEE 802.11n (2.4GHz/5GHz): from 6.5 to 300Mbps (from MCS0 to MCS15)
· IEEE 802.11ac (5GHz): from 6.5 to 867Mbps (from MCS0 to MSC9)
Transmitter output power
The maximum value of the transmitter
output power depends upon the radio
frequency regulations applied in your
country
· 802.11a (typical at room temperature 25 °C)
17dBm (±1dB) at 6Mbps
14dBm (±1dB) at 54Mbps
· 802.11g (typical at room temperature 25 °C)
16dBm (±1dB) at 6, 9, 12, 18, 24, 36Mbps
14dBm (±1dB) at 48, 54Mbps
· 802.11n (typical at room temperature 25 °C)
2.4GHz, HT20
16dBm (±1dB) at MCS0~5
14dBm (±1dB) at MCS6~7
2.4GHz, HT40
15dBm (±1dB) at MCS0~5
13dBm (±1dB) at MCS6~7
· 802.11ac (typical at room temperature 25 °C)
17dBm (±1dB) at MCS0
13dBm (±1dB) at MCS9
