DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Overview
Product Appearance
Upper Panel
Figure 1. Upper panel view.
LED Mode Description
POWER/WPS
Solid red
The device is being loaded.
Solid green
The device is ready for use.
Blinking red
Attempting to add a wireless device via the
WPS function.
No light
The extender is powered off.
Wi-Fi Signal Strength
Solid red
The device is not connected to a wireless
network or the signal strength is poor.
Solid green
Fair signal strength.
Solid green
Good signal strength.
Solid green
Excellent signal strength.
No light
The 2.4GHz and 5GHz bands are off.
The Wi-Fi Signal Strength LED is a LED scale. It shows the signal strength of the wireless
network to which DAP-1610 is connected. The more LEDs are on, the better the signal strength is.
To improve the signal strength, move the extender closer to the source of the signal.
