32D-Link DAP-1610 User Manual
Section 3 - Conguration
Once your Internet connection is set up, you can view the details of both the
uplink network and the extended Wi-Fi network by clicking on the DAP-1610
icon.
Upon clicking the Uplink Router icon, you will see the connection type, network
status, connection up time, network name (SSID), and password.
If you wish to connect to a dierent uplink router, press the Connect to a
dierent uplink router button.
After clicking Connect to a dierent uplink router a survey of available wireless
networks will be performed. After clicking Select you will be prompted for the
uplink router password. Enter it and click Connect.
DIR-860L
“DIR-860L-5GHz”
DIR-860L
DIR-860L-5GHz
Select
DIR-850L-5GHz
DIR-850L
