DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Connections Setup
In this menu you can configure basic parameters of the extender for operation in the local network.
LAN
To configure the extender's basic parameters, go to the Connections Setup / LAN page.
IPv4
Go to the IPv4 tab to change IPv4 address and configure the built-in DHCP server.
Figure 33. Configuring the local interface. The IPv4 tab. The Local IP Address section.
Parameter Description
Local IP Address
Mode of local IP
address assignment
Select the needed value from the drop-down list.
Static: the IP address, subnet mask, and the gateway IP address are
assigned manually.
Dynamic: the extender automatically obtains these parameters from
the LAN DHCP server or from the router to which it connects.
IP address
The IP address of the extender in the local subnet. By default, the
following value is specified: 192.168.0.50.
Subnet mask
The mask of the local subnet. By default, the following value is
specified: 255.255.255.0.
Gateway IP address
The gateway IP address which is used by the extender to connect to
the Internet (e.g., for synchronizing the system time with an NTP
server). Optional.
Device domain name The name of the device assigned to its IP address in the local subnet.
When needed settings are configured, click the APPLY button.
Page 38 of 91
