D-Link DAP-1620 User Manual

DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the opened window, in the System Time field, the system time of the device is displayed. You
can select the Simplified mode choice of the radio button and specify the following parameters:
Parameter Description
Simplified mode
Interval of execution
Specify the time period for the device's reboot.
Every day: When this value is selected, the Time field is displayed
in the section.
Every week: When this value is selected, the names of days of the
week and the Time field are displayed in the section.
Every month: When this value is selected, the Day of month and
Time fields are displayed in the section.
Time
Specify the time for the device's reboot.
Days of week
Select a day or days of the week when the device will be
automatically rebooted. To do this, select the checkbox located to the
left of the relevant value.
Day of month
Specify a day of the month. You can specify one value or several
values separated by a comma.
In the advanced mode, you can specify more parameters for the schedule using a cron expression.
To do this, select the Advanced mode choice of the radio button and specify the needed values in
the fields displayed. You can specify one value or several values separated by a comma. You can
use the character * (asterisk) to specify the entire range of possible values. Upon that the Schedule
field will be filled in automatically.
Click the SAVE button.
To edit the automatic reboot schedule, click the EDIT button in the Auto Reboot section. In the
opened window, change the needed parameters and click the SAVE button.
To disable automatic reboot of the device on a schedule, click the EDIT button in the Auto
Reboot section. In the opened window, click the DISABLE button.
Page 107 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
