DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the Static IP Addresses section, you can specify MAC address and IPv4 address pairs (set a
fixed IPv4 address in the local area network for a device with a certain MAC address). The extender
assigns IPv4 addresses in accordance with the specified pairs only when the DHCP server is
enabled (in the Dynamic IP Addresses section, the Server value is selected from the Mode of
dynamic IP address assignment drop-down list).
Figure 48. Configuring the local interface. The IPv4 tab. The section for creating MAC-IPv4 pairs.
To create a MAC-IPv4 pair, click the ADD button ( ). In the opened window, fill in the MAC
address field. You can choose a device connected to the extender's LAN at the moment. To do
this, select the relevant MAC address from the drop-down list (the field will be filled in
automatically). Then in the IP address field, enter an IPv4 address which will be assigned to the
device with the specified MAC address. In the Hostname field, specify a network name of the
device for easier identification (optional). Click the APPLY button.
To create MAC-IPv4 pairs for the devices connected to the extender at the moment, click the
KNOWN CLIENTS button. In the opened window, select the needed device and click the OK
button. To view the latest list of the connected devices, click the REFRESH button.
To edit the settings for an existing MAC-IPv4 pair, left-click the relevant line in the table. In the
opened window, change the needed parameters and click the APPLY button.
To remove a MAC-IPv4 pair, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ). Then click the APPLY button. Also you can remove a pair in
the editing window.
Page 57 of 125
