Configuring via Web-based Interface
Parameter Description
Max associated clients
The maximum number of devices connected to the wireless network.
When the value 0 is specified, the device does not limit the number
of connected clients.
Enable shaping
Move the switch to the right to limit the maximum bandwidth of the
wireless network. In the Shaping field displayed, specify the
maximum value of speed (Mbit/s).
Move the switch to the left not to limit the maximum bandwidth.
Broadcast wireless
network
If the wireless network broadcasting is disabled, devices cannot
connect to the wireless network. Upon that DAP-1620 can connect
to another access point as a wireless client.
To enable/disable broadcasting on a schedule, click the Set
schedule button ( ). In the opened window, you can create a
new schedule (see the Schedule section, page 106) or use the
existing one. Existing schedules are displayed in the Interval of
execution drop-down list in the simplified mode.
To enable broadcasting at the time specified in the schedule and
disable it at the other time, select the Enable wireless network
broadcasting value from the Action drop-down list and click the
SAVE button. When the wireless connection is disabled, the device
will not be able to enable broadcasting of this wireless network on
schedule.
To disable broadcasting at the time specified in the schedule and
enable it at the other time, select the Disable wireless network
broadcasting value from the Action drop-down list and click the
SAVE button.
To change or delete the schedule, click the Set schedule button
( ). In the opened window, change the parameters and click the
SAVE button or click the DELETE FROM SCHEDULE button.
If you created an additional network, you can configure, change or
delete a schedule for each network. To do this, click the button in the
line of the network.
Clients isolation
Move the switch to the right to forbid wireless clients of this
wireless network to communicate to each other.
Page 64 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
