D-Link DAP-1620 User Manual

DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Overview
Wireless Module Parameters
Receiver sensitivity
· 802.11a (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)
-93dBm at 6Mbps
-91dBm at 9Mbps
-90dBm at 12Mbps
-87dBm at 18Mbps
-84dBm at 24Mbps
-81dBm at 36Mbps
-76dBm at 48Mbps
-75dBm at 54Mbps
· 802.11b (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)
-94dBm at 2Mbps
-89dBm at 11Mbps
· 802.11g (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)
-94dBm at 6Mbps
-92dBm at 9Mbps
-91dBm at 12Mbps
-88dBm at 18Mbps
-85dBm at 24Mbps
-82dBm at 36Mbps
-77dBm at 48Mbps
-76dBm at 54Mbps
· 802.11n, 2.4GHz (typical at PER = 10% (1000-byte PDUs) at room
temperature 25 °C)
HT20
-93dBm at MCS0/8
-90dBm at MCS1/9
-88dBm at MCS2/10
-85dBm at MCS3/11
-81dBm at MCS4/12
-77dBm at MCS5/13
-76dBm at MCS6/14
-74dBm at MCS7/15
HT40
-91dBm at MCS0/8
-88dBm at MCS1/9
-85dBm at MCS2/10
-82dBm at MCS3/11
-79dBm at MCS4/12
-75dBm at MCS5/13
-73dBm at MCS6/14
-72dBm at MCS7/15
· 802.11n, 5GHz (typical at PER < 10% at room temperature 25 °C)
HT20
-92dBm at MCS0/8
-89dBm at MCS1/9
-87dBm at MCS2/10
-84dBm at MCS3/11
-80dBm at MCS4/12
-76dBm at MCS5/13
-75dBm at MCS6/14
-73dBm at MCS7/15
HT40
-90dBm at MCS0/8
-86dBm at MCS1/9
-84dBm at MCS2/10
-80dBm at MCS3/11
-77dBm at MCS4/12
-73dBm at MCS5/13
-71dBm at MCS6/14
-70dBm at MCS7/15
Page 8 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
