D-Link DAP-1620 User Manual

DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Parameter Description
Use multicast for
service data exchange
Move the switch to the right in order to use multicast traffic for
service data exchange between access points (routers, extenders).
This setting is needed if the devices which support the smart
adjustment function are located in different subnets. If the switch is
moved to the right, the Multicast TTL and Multicast group
address fields are displayed on the page.
If the switch is moved to the left, broadcast traffic is used for service
data exchange.
Multicast TTL
Specify the TTL (Time to live) parameter value. The recommended
value is 4.
Multicast group
address
Specify the address of the multicast group (from the subnet
239.255.0.0/16).
2.4 GHz / 5 GHz
Maximum time of
storing data
The maximum time period (in seconds) during which the extender
(access point) stores data on the signal strength of the client located
on its coverage area.
Minimum level of
connection quality
The signal strength upon which the extender (access point) starts
scanning other devices in order to find a device with a higher signal
level.
Dead zone
This parameter is used for calculation of the signal strength upon
which the smart adjustment function goes off. If the signal strength
provided by another device is less than the sum of the Minimum
level of connection quality field value and the Dead zone field
value, then the client disconnects from the extender (access point).
You can specify the values from -50% to +50%.
Threshold value of
connection quality
The signal strength upon which the extender (access point)
disconnects the client from its wireless network regardless of the
signal levels of other devices. This value should not be greater than
the value specified in the field Minimum level of connection
quality.
After specifying the needed parameters, click the APPLY button.
To disable the function of smart adjustment of Wi-Fi clients, click the DISABLE button.
Page 92 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
