DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Enable rule
Move the switch to the right to enable the rule.
Move the switch to the left to disable the rule.
Action
Select an action for the rule.
• Deny: Blocks access to the Internet for the device with the
specified MAC address even if the default mode allows
access for all devices.
• Allow: Allows access to the extender's network and to the
Internet for the device with the specified MAC address even
if the default mode denies access for all devices.
MAC address
The MAC address of a device from the extender's LAN. You can
enter the MAC address of a device connected to the extender's LAN
at the moment. To do this, select the relevant device from the drop-
down list (the field will be filled in automatically).
After specifying the needed parameters, click the SAVE button.
To edit a rule, select the relevant line in the table. In the opened window, change the needed
parameters and click the SAVE button.
To remove a rule, select the checkbox located to the left of the relevant line of the table and click
the DELETE button ( ). Also you can remove a rule in the editing window.
Page 99 of 125
