VLAN
The DAP-2660 supports VLANs. VLANs can be created with a Name and VID. Mgmt (TCP stack), LAN, Primary/Multiple SSID, and WDS connection
can be assigned to VLANs as they are physical ports. Any packet which enters the DAP-2660 without a VLAN tag will have a VLAN tag inserted
with a PVID. The VLAN List tab displays the current VLANs.
VLAN Status:
VLAN Mode:
VLAN List:
Port List:
Add/Edit VLAN:
PVID Settings::
Select to Enable or Disable the VLAN status here.
The current VLAN mode is displayed.
In this tab, a list of congured VLAN, with their
respective parameters will be displayed.
In this tab, a list of ports, with their respective
VLAN congurations, will be displayed.
In this tab, we can add or modify VLANs congured
on this access point.
In the tab, we can congure the PVID settings for
the VLANs congured in this access point.
VLAN List
