D-Link DAP-2695 Command Line Interface Reference Manual

802.11 b/g /n Access Point Command Line Interface Manual
3
1
USING THE CLI
The DAP-2695 can be accessed by Telnet. Using Microsoft Windows Operation system as example, open the Command Prompt on the computer that will be used for
configuring and managing the AP and enter telnet and IP address of DAP-2695 in the first line. Using the default IP address as example, enter telnet 192.168.0.50 to
cause thefollowing screen to open: (picture on the left)
Press Enter in the screen above. The following screen opens: (picture on the right)

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
