D-Link DAP-2695 Command Line Interface Reference Manual

802.11 b/g /n Access Point Command Line Interface Manual
10
4
ETHERNET COMMANDS
Get Command:
Function
Syntax
get ipaddr
Display IP Address
get ipaddr
get ipmask
Display IP Network/Subnet Mask
get ipmask
get gateway
Display Gateway IP Address
get gateway
get ipmode
Display IP Mode
get ipmode
get eth-updownlink
Display ethernet uplink/downlink state
get eth-updownlink
get updownlink
Display primary ssid uplink/downlink state
get updownlink
get uplink_bandwidth
Display uplink bandwidth
get uplink_bandwidth
get downlink_bandwidth
Display downuplink bandwidth
get downlink_bandwidth
get nameaddr
Display DNS Address
get nameaddr
get ipv6
Display IPv6 settings
get ipv6
Set Command:
Function
Syntax
set ipaddr
Set IP Address
set ipaddr <xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
set ipmask
Set IP Network/Subnet Mask
set ipmask < xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is Network
mask
set gateway
Set Gateway IP Address
set gateway <xxx.xxx.xxx.xxx>
Explanation: <xxx.xxx.xxx.xxx> is IP address
set ipmode
Set IP Mode(Static or Dynamic)
set ipmode
set eth-updownlink
Set ethernet uplink/downlink state
set eth-updownlink [link/down/none]
set fixedrate
Set Fixed Rate
set fixedrate

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
