D-Link DAP-2695 Command Line Interface Reference Manual

802.11 b/g /n Access Point Command Line Interface Manual
38
16
FIRST-TIME CONFIGURATION EXAMPLES
The following AP configuration examples are provided to help first-time users get started. The user commands are in bold for easy reference.
Many users will want to set a new IP address for the DAP-2695. This will also require setting an IP mask and a Gateway IP address. The following is an example in
which the AP’s default IP address of 192.168.0.50 is changed to 192.168.0.55.
WAP -> set ipaddr 192.168.0.55
WAP -> set ipmask 255.255.255.0
WAP -> set gateway 192.168.0.254
WAP -> set channel 6
WAP -> set ssid DAP-2695
Once the user has determined what type of authentication is best for their wireless network, follow the appropriate instructions below.
The following is an example in which authentication is set to Open System.
WAP -> set authentication open-system
The following is an example in which the authentication is set to Shared-Key.
WAP -> set authentication shared-key
WAP -> set keyentrymethod asciitext 1
WAP -> set keylength 64Bit 1
WAP -> set key 1 12345
WAP -> set defkeyindex 1

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
