D-Link DAP-2695 Command Line Interface Reference Manual

802.11 b/g /n Access Point Command Line Interface Manual
39
The following is an example in which the authentication is set to WPA-PSK.
WAP -> set authentication wpa-psk
WAP -> set cipher auto
WAP -> set passphrase 12345678
Once the user has set up the AP to their satisfaction, the device must be rebooted to save settings.
WAP -> reboot

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
