53D-Link DCS-934L User Manual
Section 4 - Conguration
Note: Because a dynamic WAN IP can change from time to time depending on your ISP, you may want to obtain a Static IP address from your ISP (Internet
Service Provider). A Static IP address is a xed IP address that will not change over time and will be more convenient for you to use to access your camera
from a remote location. The Static IP address will also allow you to access your camera attached to your router over the Internet.
4. Open Virtual Server Ports to Enable Remote Image Viewing
The rewall security features built into the DIR-655 router prevent users from accessing the video from the DCS-934L over the Internet. The router
connects to the Internet over a series of numbered ports. The ports normally used by the DCS-934L are blocked from access over the Internet.
Therefore, these ports need to be made accessible over the Internet. This is accomplished using the Virtual Server function on the DIR-655 router.
The Virtual Server ports used by the camera must be opened through the router for remote access to your camera. Virtual Server is accessed by
clicking on the Advanced tab of the router screen.
1. Click Enabled.
2. Enter a dierent name for each entry.
3. Enter your camera’s local IP address (e.g., 192.168.0.120) in the Private IP eld.
4. Select TCP for HTTP port and TCP for 5556 - 5559 ports.
5. If you are using the default camera port settings, enter 80 into the Public and Private Port section, click Apply.
6. Scheduling should be set to Always so that the camera images can be accessed at any time.
Note: Instructions for Virtual Server continue on the next page.
Follow these steps to congure your router’s Virtual Server settings:
