Example 3.22. Setting up a Time-Scheduled Security Policy
This example creates a schedule object for office hours on weekdays, and attaches the object to an IP Rule that
allows HTTP traffic.
Command-Line Interface
gw-world:/> add ScheduleProfile OfficeHours
Mon=8-17 Tue=8-17 Wed=8-17 Thu=8-17 Fri=8-17
Now create the IP rule that uses this schedule. First, change the current category to be the main IP rule set:
gw-world:/> cc IPRuleSet main
Now, create the IP rule:
gw-world:/main> add IPRule Action=NAT
Service=http
SourceInterface=lan
SourceNetwork=lannet
DestinationInterface=any
DestinationNetwork=all-nets
Schedule=OfficeHours name=AllowHTTP
Return to the top level:
gw-world:/main> cc
Configuration changes must be saved by then issuing an activate followed by a commit command.
Web Interface
1. Go to: Objects > Schedules > Add > Schedule
2. Enter the following:
• Name: OfficeHours
3. Select 08-17, Monday to Friday in the grid
4. Click OK
1. Go to: Rules > IP Rules > Add > IPRule
2. Enter the following:
• Name: AllowHTTP
3. Select the following from the dropdown lists:
• Action: NAT
• Service: http
• Schedule: OfficeHours
• SourceInterface: lan
• SourceNetwork lannet
• DestinationInterface: any
• DestinationNetwork: all-nets
4. Click OK
3.7. Schedules Chapter 3. Fundamentals
149
