Important: Ensure all-nets appears in the main table
A common mistake when setting up policy-based routing is the absence of a default
route with a destination interface of all-nets in the default main routing table.
If there is no route that is an exact match then the absence of a default all-nets route
will mean that the connection will be dropped.
Example 4.7. Policy-based Routing with Multiple ISPs
This example illustrates a multiple ISP scenario which is a common use of policy-based routing. The following is
assumed:
• Each ISP will provide an IPv4 network from its network range. A 2 ISP scenario is assumed in this case, with
the network 10.10.10.0/24 belonging to ISP A and 20.20.20.0/24 belonging to ISP B. The ISP provided
gateways are 10.10.10.1 and 20.20.20.1 respectively.
• All addresses in this scenario are public addresses for the sake of simplicity.
• This is a "drop-in" design, where there are no explicit routing subnets between the ISP gateways and the
NetDefend Firewall.
In a provider-independent network, clients will likely have a single IP address, belonging to one of the ISPs. In a
single-organization scenario, publicly accessible servers will be configured with two separate IP addresses: one
from each ISP. However, this difference does not matter for the policy routing setup itself.
Note that, for a single organization, Internet connectivity through multiple ISPs is normally best done with the BGP
protocol, which means not worrying about different IP spans or about policy routing. Unfortunately, this is not
always possible, and this is where Policy Based Routing becomes a necessity.
We will set up the main routing table to use ISP A and add a named routing table called r2 that uses the default
gateway of ISP B.
Interface Network Gateway ProxyARP
lan1 10.10.10.0/24 wan1
lan1 20.20.20.0/24 wan2
wan1 10.10.10.1/32 lan1
wan2 20.20.20.1/32 lan1
wan1 all-nets 10.10.10.1
Contents of the named Policy-based Routing table r2:
Interface Network Gateway
wan2 all-nets 20.20.20.1
The table r2 has its Ordering parameter set to Default, which means that it will only be consulted if the main
routing table lookup matches the default route (all-nets).
Contents of the Policy-based Routing Policy:
Source
Interface
Source
Range
Destination
Interface
Destination
Range
Selected/
Service
Forward
VR table
Return
VR table
lan1 10.10.10.0/24 wan2 all-nets ALL r2 r2
wan2 all-nets lan1 20.20.20.0/24 ALL r2 r2
To configure this example scenario:
Web Interface
1. Add the routes found in the list of routes in the main routing table, as shown earlier.
4.3. Policy-based Routing Chapter 4. Routing
191
