• Name: A suitable name for the rule, for example Queries_if1
• Type: Query
• Action: Proxy
• Output: if1 (this is the relay interface)
3. Under Address Filter enter:
• Source Interface: wan
• Source Network: UpstreamRouterIp
• Destination Interface: core
• Destination Network: auto
• Multicast Source: 192.168.10.1
• Multicast Group: 239.192.10.0/24
4. Click OK
Example 4.19. if2 Configuration - Group Translation
The following steps needs to be executed to create the report and query rule pair for if2 which translates the
multicast group. Note that the group translated therefore the IGMP reports include the translated IP addresses
and the queries will contain the original IP addresses
Web Interface
A. Create the first IGMP Rule:
1. Go to: Network > Routing > IGMP Rules > Add > IGMP Rule
2. Under General enter:
• Name: A suitable name for the rule, for example Reports_if2
• Type: Report
• Action: Proxy
• Output: wan (this is the relay interface)
3. Under Address Filter enter:
• Source Interface: if2
• Source Network: if2net
• Destination Interface: core
• Destination Network: auto
• Multicast Source: 192.168.10.1
• Multicast Group: 239.192.10.0/24
4. Click OK
B. Create the second IGMP Rule:
1. Again, go to: Network > Routing > IGMP Rules > Add > IGMP Rule
2. Under General enter:
4.6.3. IGMP Configuration Chapter 4. Routing
236
