gw-world:/1(ImportOSPFRoutes)> add DynamicRoutingRuleAddRoute
Destination=main
Web Interface
1. Go to: Routing > Dynamic Routing Rules
2. Click on the newly created ImportOSPFRoutes
3. Go to: Routing Action > Add > DynamicRoutingRuleAddRoute
4. Move the routing table main from Available to Selected
5. Click OK
The same procedure should be repeated for firewall B.
Example 4.13. Exporting the Routes into an OSPF AS
In this example, routes from the main routing table will be exported into an OSPF AS named as_0. This must be
done explicitly because routes are not exported automatically.
The exception to this are the routes for the OSPF interface networks which are exported automatically (in this
example If1_net and If3_net).
The steps are first performed for firewall A.
First, add a new Dynamic Routing Policy Rule.
Command-Line Interface
gw-world:/> add DynamicRoutingRule
OSPFProcess=as_0
Name=ExportDefRoute
DestinationNetworkIn=all-nets
DestinationInterface=If3
From=RTable
RoutingTable=main
Web Interface
1. Go to: Routing > Dynamic Routing Rules > Add > Dynamic Routing Policy Rule
2. Specify a name for the rule. In this case, ExportAllNets
3. Select the option From Routing Table
4. Move the routing table main to the Selected list
5. Choose all-nets in the ...Or is within filter for Destination Interface
6. Click OK
Next, create an OSPF Action that will export the filtered route to the specified OSPF AS:
Command-Line Interface
First, change the CLI context to be the DynamicRoutingRule just added for export:
gw-world:/> cc DynamicRoutingRule ExportDefRoute
Next, add a DynamicRoutingRuleExportOSPF object:
gw-world:/2(ExportDefRoute)> add DynamicRoutingRuleExportOSPF
ExportToProcess=as_0
4.5.6. An OSPF Example Chapter 4. Routing
223
