D-Link DIR-518L User Manual

96D-Link DIR-518L User Manual
Section 6 - Connecting a Wireless Client
Windows® 7
1. Click on the wireless icon in your system tray (lower-right corner).
2. The utility will display any available wireless networks in your area.
Wireless Icon
WPA/WPA2
It is recommended to enable wireless security (WPA/WPA2) on your wireless router or access point before conguring your
wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.

D-Link DIR-518L Specifications

General

Device Type	Wireless Router
Wireless Standard	802.11n
Frequency Band	2.4 GHz
Maximum Wireless Speed	300 Mbps
USB Ports	1 x USB 2.0
Dimensions	6.5 x 4.1 x 1.3 in
Weight	0.5 lbs
USB Functionality	File Sharing, Printer Sharing
Antennas	2
Ports	1 x 10/100 Mbps WAN, 1 x 10/100 Mbps LAN
Security	WPA/WPA2
Wireless Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Antenna	2 x External Antennas
Ethernet Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
