5D-Link DIR-518L User Manual
Section 1 - Product Overview
Hardware Overview
Front/Top
1
Router/Charger
Switch
Slide the switch to Router to operate the unit in router modes.
1
Slide the switch to Charger to charge devices connected via USB.
2
Power/Status LED
Green (Solid) The device is connected and working properly.
Green (Blinking) The device is currently connecting via WPS.
Orange (Blinking)
The device cannot connect or provision an IP address
from the uplink side.
Orange (Solid) The device is booting or resetting.
Red (Blinking) The device is in recovery mode.
O The device is turned o or in charging mode.
2
1
