D-Link DSL-124 User Manual

55D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Disabling encryption and leaving your wireless network open is not recommended.
Any wireless client will be able to access your network, be able to use your Internet
connection, and leaves you open to security threats.
Encryption: Choose None from the drop-down menu.
No configuration settings are available if Encryption is set to None.
The following settings are available if Use 802.1x Authentication is checked:
Authentication
RADIUS Server:
Enter the Port, IP address, and Password of the RADIUS Server.
WIRELESS SECURITY SETTINGS
Click Apply Changes to have your changes take effect.
Encryption: None

D-Link DSL-124 Specifications

General

Wireless Standard	802.11b/g/n
Frequency Band	2.4GHz
LAN Ports	4 x 10/100Mbps
Security	WPA/WPA2
Antenna	2 x External Antennas
Wired Ports	1 x RJ-11 ADSL port
ADSL Standards	ADSL2/2+
