D-Link DSL-124 User Manual

81D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Enable: Check to enable the rule
When you are satised with your IP/Port Filtering rule, click Apply Changes to add it to the
Current Filter Table. To clear the elds and start over, click Reset. To see help on creating
rules, click Help.
RULE CONFIGURATION CONTINUED
IPv6/Port Filter (continued)
CURRENT FILTER TABLE
The current lter rules in eect are listed here. Click Disable/Enable to disable or enable a
rule. Click Delete to delete a rule.

D-Link DSL-124 Specifications

General

Wireless Standard	802.11b/g/n
Frequency Band	2.4GHz
LAN Ports	4 x 10/100Mbps
Security	WPA/WPA2
Antenna	2 x External Antennas
Wired Ports	1 x RJ-11 ADSL port
ADSL Standards	ADSL2/2+
