DSL-2750E User Manual
72
The following table describes the parameters of this page.
Field Description
Destination
Network Address
The destination IPv6 address of the router.
Use Interface The interface name of the router output port.
Click Apply to save the settings.
3.3.13.3 Policy Route
Choose ADVANCED > Routing and click IPv6 Static Route. The page shown in
the following figure appears. The policy route binds one WAN connection and
one LAN interface.
Click add, the page shown in the following figure appears.

D-Link DSL-2750E Specifications

ADSL Standards

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface	RJ-45 port for 10/100BASE-T Ethernet connection
