DVG-5402G/GF Wireless AC1200 Wave 2 MU-MIMO Dual
Band Gigabit Router with Fiber WAN Port, 3G/LTE Support,
2 FXS Ports, and USB Port
User Manual
Configuring via Web-based Interface
If you want to specify the list of accounts to provide access to this server, click the ADD ( )
button in the Users List section.
Figure 122. A window for adding a user.
In the opened window, you can specify the following parameters:
Parameter Description
User Select a user account to allow access.
Set IP address
The mode of IP address assignment. Select a value from the drop-
down list.
• Auto: The IP address is assigned to the user automatically.
• Single IP: The IP address is assigned to the user manually.
When this value is selected, the IP address field is
displayed.
IP address
Specify an IP address from the range specified in the Start client
IP and End client IP fields.
Click the SAVE button.
To edit an existing user, in the Users List section, select the relevant line in the table. In the
opened window, change the needed parameters and click the SAVE button.
To remove a user, in the Users List section, select the checkbox located to the left of the relevant
line in the table and click the DELETE button ( ).
After specifying the needed parameters, click the APPLY button.
To disable the server, move the Enable switch to the left and click the APPLY button.
