DVG-5402G/GF Wireless AC1200 Wave 2 MU-MIMO Dual
Band Gigabit Router with Fiber WAN Port, 3G/LTE Support,
2 FXS Ports, and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
IP address RADIUS
server
The IP address of the RADIUS server.
RADIUS server port A port of the RADIUS server.
RADIUS encryption key
The password which the router uses for communication with the
RADIUS server (the value of this parameter is specified in the
RADIUS server settings).
Encryption type An encryption method: TKIP, AES, or TKIP+AES.
Group key update
interval
The time period (in seconds), at the end of which a new key for
WPA encryption is generated. When the value 0 is specified for this
field, the key is not renewed.
802.11w (Protected
Management Frames)
For WPA2 authentication type only.
Protected Management Frames help to improve packet privacy
protection for wireless data transmission. Select a value for the
wireless network from the drop-down list.
• Disabled: Protected Management Frames are not used.
• Optional: Protected Management Frames are optional.
• Required: Protected Management Frames are required.
When this value is selected, devices not supporting the
802.11w standard cannot connect to the wireless network.
When you have configured the parameters, click the APPLY button.
To edit the basic or additional wireless network, left-click the relevant line in the table. On the
opened page, change the needed parameters and click the APPLY button.
To remove the additional network, select the checkbox located to the left of the relevant line in the
table and click the DELETE button ( ). Then click the APPLY button.
Page 177 of 352
