DVG-5402G/GF Wireless AC1200 Wave 2 MU-MIMO Dual
Band Gigabit Router with Fiber WAN Port, 3G/LTE Support,
2 FXS Ports, and USB Port
User Manual
Configuring via Web-based Interface
Figure 144. The window for adding a rule for the MAC filter.
You can specify the following parameters:
Parameter Description
Frequency band
From the drop-down list, select a band of the wireless network.
SSID
A wireless network to which the rule will be applied. Select the
needed value from the drop-down list.
MAC address
In the field, enter the MAC address to which the selected filtering
mode will be applied.
Name
The name of the device for easier identification. You can specify any
name.
Enable
If the switch is moved to the right, the rule is active.
Move the switch to the left to disable the rule.
When you have configured the parameters, click the SAVE button.
To edit the parameters of the existing rule, in the Filters section, left-click the needed rule. In the
opened window, change the settings and click the SAVE button.
To remove the rule from the page, in the Filters section, select the checkbox located to the left of
the relevant rule and click the DELETE button ( ).
Page 197 of 352
