DVG-5402G/GF Wireless AC1200 Wave 2 MU-MIMO Dual
Band Gigabit Router with Fiber WAN Port, 3G/LTE Support,
2 FXS Ports, and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
SIP Domain
Use domain to register
Move the switch to the right if your ISP requires to specify a domain
name upon registration on the SIP proxy server. Then fill in the SIP
domain name field.
SIP domain name
When this field is filled in, the router registers on the SIP proxy
server using the specified domain name. When the field is blank, the
router uses the IP address assigned to it.
Misc
Local RTP port
(minimum / maximum)
A range of ports for voice traffic receipt/transfer via RTP. Unless
another setting is given by your ISP, it is recommended to leave the
default value (9000 and 9100).
DNS Interface
Select the interface which will be used for domain name resolution
in VoIP. Leave the Follow VoIP value if changing the interface for
domain name resolution is not required.
Also on this page, you can specify incoming/outgoing call settings for the SIP lines.
Figure 200. The VoIP / Profile Name / Basic Settings. The List of SIP Lines section.
To change parameters of a SIP line, select the relevant line in the table.
Page 267 of 352
