4D-Link M32 User Manual
Section 1 - Product Overview
Hardware Overview
M32 LED Indicator
1 Status LED
Solid red The M32 is booting up.
Blinking orange
The M32 is syncing to another M32 Mesh Router.
Once set up, a blinking orange LED indicates there is no connection to the device.
Solid white
The M32 is powered on and running.
Once set up, a solid white LED indicates a strong connection.
Blinking white
Once set up, a blinking white LED indicates a weak connection, or the M32 is connecting to a
wireless client using Wi-Fi Protected Setup (WPS).
O
The M32 is powered o.
If the device is powered on and Status LED is disabled, the device is working as normal. Refer to
the Admin section on page 61 for more information.
1
