D-Link N150 User Manual

6D-Link DHP-1220AV User Manual
Section 1 - Product Overview
1 Power Button Press to power on/o the device.
2
Simple Connect
Button
Push this button to create a secure Powerline connection with another adapter. It can also be used to
connect using Wi-Fi Protected Setup (WPS). To connect using WPS, press this button, then press the WPS
button on your wireless client. To reset the device to factory settings, press the button for 10 seconds.
Hardware Overview
Buttons
2
1

D-Link N150 Specifications

General

AC input	100 - 240 V AC, 50/60 Hz
ethernet	10/100 Mbps
WLAN	Up to 150 Mbps
powerline	Up to 200 Mbps
frequency range	2.4 GHz to 2.497 GHz
operating temperature	0 to 40 °C (32 to 104 °F)
storage temperature	-20 to 65 °C (-4 to 149 °F)
humidity operation	10% to 90% non-condensing
humidity storage	5% to 95% non-condensing

Weight and Dimensions

dimensions	73 x 58 x 37 mm (2.87 x 2.28 x 1.46 inches)
weight	96 grams (3.39 ounces)
