13D-Link DHP-1220AV User Manual
Section 3 - Conguration
Select Dynamic IP (DHCP) to obtain IP address information
automatically from your ISP. Select this option if your ISP does
not give you any IP numbers to use. This option is commonly
used for cable modem services.
The host name is optional but may be required by some ISPs.
Leave blank if you are not sure.
Check the box if you are having problems obtaining an IP
address from your ISP.
Select Auto to automatically detect the primary domain name
server IP address, or Manual to enter it yourself.
It will automatically display the IP address or you can enter it
here.
Enter an optional secondary domain name server.
Maximum Transmission Unit - you may need to change the
MTU for optimal performance with your specic ISP. 1500 is
the default MTU.
The default MAC address is set to the Internet port’s physical
interface MAC address on the broadband router. You can use
the Clone Your PC’s MAC Address button to replace the
Internet port’s MAC address with the MAC address of your
Ethernet card (not recommended).
Connection
Type:
Host Name:
Use
Unicasting:
Domain Name
Server
Assignment:
Primary
Domain Name
Server:
Secondary
Domain Name
Server:
MTU:
MAC Address:
Internet
Dynamic IP (DHCP)
If you are unsure what method you use to connect to the Internet, try this rst. Cable modems usually use this type of connection.

D-Link N150 Specifications

General

AC input	100 - 240 V AC, 50/60 Hz
ethernet	10/100 Mbps
WLAN	Up to 150 Mbps
powerline	Up to 200 Mbps
frequency range	2.4 GHz to 2.497 GHz
operating temperature	0 to 40 °C (32 to 104 °F)
storage temperature	-20 to 65 °C (-4 to 149 °F)
humidity operation	10% to 90% non-condensing
humidity storage	5% to 95% non-condensing

Weight and Dimensions

dimensions	73 x 58 x 37 mm (2.87 x 2.28 x 1.46 inches)
weight	96 grams (3.39 ounces)
