D-Link N150 User Manual

14D-Link DHP-1220AV User Manual
Section 3 - Conguration
Static IP
Select Static IP to manually enter the IP settings supplied by
your ISP.
Enter the IP address assigned by your ISP.
Enter the subnet mask assigned by your ISP.
Enter the gateway assigned by your ISP.
The DNS server information will be supplied by your ISP
Maximum Transmission Unit - you may need to change the
MTU for optimal performance with your specic ISP. 1500 is
the default MTU.
The default MAC address is set to the Internet port’s physical
interface MAC address on the broadband router. It is not
recommended that you change the default MAC address unless
required by your ISP. You can use the Clone Your PC’s MAC
Address button to replace the Internet port’s MAC address
with the MAC address of your Ethernet card.
My Internet
Connection Is:
IP Address:
Subnet Mask:
Default
Gateway:
DNS Servers:
MTU:
MAC Address:

D-Link N150 Specifications

General

AC input	100 - 240 V AC, 50/60 Hz
ethernet	10/100 Mbps
WLAN	Up to 150 Mbps
powerline	Up to 200 Mbps
frequency range	2.4 GHz to 2.497 GHz
operating temperature	0 to 40 °C (32 to 104 °F)
storage temperature	-20 to 65 °C (-4 to 149 °F)
humidity operation	10% to 90% non-condensing
humidity storage	5% to 95% non-condensing

Weight and Dimensions

dimensions	73 x 58 x 37 mm (2.87 x 2.28 x 1.46 inches)
weight	96 grams (3.39 ounces)
