D-Link N150 User Manual

41D-Link DHP-1220AV User Manual
Section 4 - Connecting to a Wireless Network
Windows® 7
1. Click on the wireless icon in your system tray (lower-right corner).
2. The utility will display any available wireless networks in your area.
Wireless Icon
WPA/WPA2
It is recommended to enable wireless security (WPA/WPA2) on your wireless router or access point before conguring your
wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.

D-Link N150 Specifications

General

AC input	100 - 240 V AC, 50/60 Hz
ethernet	10/100 Mbps
WLAN	Up to 150 Mbps
powerline	Up to 200 Mbps
frequency range	2.4 GHz to 2.497 GHz
operating temperature	0 to 40 °C (32 to 104 °F)
storage temperature	-20 to 65 °C (-4 to 149 °F)
humidity operation	10% to 90% non-condensing
humidity storage	5% to 95% non-condensing

Weight and Dimensions

dimensions	73 x 58 x 37 mm (2.87 x 2.28 x 1.46 inches)
weight	96 grams (3.39 ounces)
