Overall Length: A = Fabric Width + 7" (28 Cm)
Length B is the distance between mounting holes on brackets
and is the fabric width.
Wall Mounting
Ceiling Mounting
Surface
Place “D” Rings Over
Hooks
Well Secured In
Ceiling.
Surface
Ceiling
“V” Bar
Mounted To
The Wall
Wall
“V” Bar Mounted
To The Back Of
The Case At The
Factory
Allow A Minimum Of
1¼" From Ceiling
Picture Surface
4¼"
4"
PRODUCT VIEWS SUGGESTED METHOD OF INSTALLATION
3½"
3½"
A
B
