DAC GDC31 - Switch; Annunciator Outline

Equipment Installation Manual,
GDC31 Roll Steering Converter
Switch / Annunciator Outline
PANEL CUTOUT
12
6
8
11
3
4
57
9
10
12
PIN OUT
(REAR VIEW)
Outline for part number P10280
Note: Dimensions are in inches.
1049-2510-01 G.doc
1049-2510-01
Rev G Page 27 of 47
